How Do Glasses Work?
75% of Americans need corrective lenses to keep their surroundings in focus, but understanding how glasses work begins with the mechanicsof the eye.
How the Eye Focuses Light
The pupil allows light into the back of the eyeThe cornea is the top layer of the eye where all light must pass through
The lens works with the cornea to fine-tune vision
The retina is a complex layer of cells that react to light
What happens when you look at the world around you?
1. Scattered light merges together and is focused on the retina
2. Images must shrink and curve to match the shape of the retina
3. Reaction to light is relayed from the retina to the brain and is translated into an image
Light rays are focused directly on the retina for those with perfect vision, but eyeglasses can bend the light, so most everyone can have 20/20 vision
When Vision Goes Askew - Glasses to the Rescue
These common vision problems occur when the eye cannot focus an image onto the retina
Myopia occurs because the image comes into focus before it reaches the retina.Close objects are in focus, distant objects are out of focus
occurs because the image doesn't come into focus before it gets to the retina. Close objects are out of focus, distant objects are in focus
In Astigmatism the shape of the lens or cornea is distorted so light makes two focal points instead of one. More curvature in one direction than in another results in blurred vision at all distances
Lenses can be cut to bring the image closer, further away, or correct other vision problems like double vision
How Do Lenses Correct Vision Problems?
What is a lens?
Two rounded prisms joined together. Prisms are always thicker at one end and light passing through it is bent/refracted towards the thicker end
Two main types of lenses
Wearing the correct type and power of lens makes up for your eye’s inability to project light on your retina
Convex/Plus (+) lens Corrects Farsightedness
Bends the light towards the bottom and top of the lens, pushing the focal point back to the retina. The stronger the lens, the closer the focal point is to the lens
Concave/Minus (-) lens Corrects Nearsightedness
Spreads the light away from the center of the lens and moves the focal point up. The stronger the lens, the farther the focal point is from the lens
Diopters (D) express the lens strength and indicate how much the light is bent
Higher diopters indicate stronger lenses
1 diopter = 1 m
2 diopters = 0.5 m
3 diopters = 0.33 meters, etc.
Plus (+) or minus (-) sign before the dioper indicates lens type
Plus and minus lenses can be combined, so the algebraic sum is the lens type
E.g., +1.00D lens + -4.00D lens = -3.00 lens
Spherical lens -Curve is the same all over the surface of the lens
Cylindrical lens -Used to correct astigmatism, typically used to focus incoming light into a line
Compound lens - Includ a spherical and a cylindrical component
So How Do You Read a Prescription?
OD 2.50 -1.50 x 123 plus +2.00
OD = Right eye
OS = Left eye
4 parts to a prescription
Spherical base strength and +/- type (+2.50D)
Cylinder strength and type (-1.50D cylinder)
Cylinder axis orientation - x means “at"(123 degrees)
Strength of bifocal segment and type (Bifocal segment of +2.00D) prescription may or may not include a small segment for bifocals or progressive lenses
